EVB Lite Vibration Sensor

SKU 364215375135193
Price

$89.00

EVB Lite Wi-Fi Vibration Sensor up to 1.6 kHz | 3-Axis Accelerometer | Wi-Fi & AP Mode | Free Device Hub Software | DIY,  Maker, Hobbyist & Personal Use Motion Sensor



Return Policy: EVident Battery offers a 30-day free return policy. If you’re not satisfied, return your purchase within 30 days of delivery for a full refund—return shipping is on us.



Product Description

a. The EVB Lite Wi-Fi Vibration Sensor delivers accurate, timestamped vibration and motion data up to 1.6 kHz sampling rate using a 3-axis accelerometer, making it ideal for DIY projects, personal experimentation, and hobbyist-level monitoring.

b. Built with Wi-Fi (2.4 GHz) for real-time streaming and optional AP Mode for offline use, users can view data directly in their browser (Free) or connect to the EVident Platform (evbdata.com, fees apply) with no software installation required.

c. EVB Lite pairs with the Free Device Hub Software, allowing users to link and manage up to 1,000 sensors from a single interface—ideal for small sensor networks, test setups, and scalable personal projects.

d. An onboard real-time clock timestamps every data packet, enabling consistent event tracking, comparison, and basic vibration analysis across sessions.

e. Compact, lightweight, and affordable, EVB Lite is designed to lower the barrier to vibration monitoring for makers, DIY builds, and home or personal projects—without the complexity of enterprise-grade systems.



Main Specifications

  • Input Voltage: 3.3 V – 5.0 V
  • Typical Current: 25 mA (avg)
  • Dimensions: 41 × 37 × 19 mm
  • Measurement Axes: Acceleration (3-Axis, ±16 g)
  • Sampling Frequency: Up to 1.6 kHz (configurable)
  • Connectivity: Wi-Fi 2.4 GHz / AP Mode
  • Output Interface: Digital (CSV / JSON via HTTP REST API)
  • Timestamp Accuracy: 1 ms
  • Measurement Accuracy: 0.0005 g
  • Battery Capacity: 500 mAh (~8 hours) runtime per charge
  • Software: Free Device Hub (supports up to 1,000 sensors)
  • Platform Access: evbdata.com (fees apply)
  • Housing: Photopolymer resin enclosure (minimal vibration damping)



Perfect for makers, students, and hobbyists —without enterprise-level complexity.



One sensor. Every direction. Instant insight
